Pulse Performance Products Electric Scooter Owner’s Manual

06.12.14
NOTE: Manual illustrations are for reference purposes only. Illustrations may not reect the exact appearance of the actual product.
Specications are subject to change without notice.
ELECTRIC SCOOTER
OWNER’S MANUAL
FOR USE WITH THE FOLLOWING PULSE PERFORMANCE PRODUCTS™ SCOOTERS
• SUPER-B
DO NOT RETURN TO STORE! QUESTIONS OR COMMENTS?
CALL (866)-434-6067
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:10
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
2 Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
WARNING: Riding an electric scooter can be a dangerous activity. Certain conditions may cause components to fail without fault of the
manufacturer. Scooter can and is intended to move and it is therefore possible to lose control, fall off and/or get into dangerous situations
that no amount of care, instruction or expertise can eliminate. If such a thing does occur you can become seriously injured or die, even when
using safety equipment and other safety precautions. RIDE AT YOUR OWN RISK AND ALWAYS USE COMMON SENSE.
This manual contains many warnings and cautions concerning the consequences of failing to inspect, maintain or properly use your electric
scooter. Since any incident can result in serious injury or even death, we do not repeat the warning of possible serious injury or death each
time such a possibility is mentioned in this manual.
APPROPRIATE RIDING ATTIRE
Always wear proper protective equipment such as:
• Approved safety helmet. (Helmet may be legally required by local law or regulation in your area.)
• Elbow pads and knees pads
• Long sleeved shirt, long pants
• Gloves
• Lace up shoes with rubber soles, never ride barefooted or in sandals, and insure that shoelaces are tied and kept out of the way of the
wheels and drive system.
RIDER USE AND PARENTAL SUPERVISION
RIDER MUST NOT EXCEED THE WEIGHT LIMIT OF 150 pounds (68 kg). Rider weight does not always mean a person’s size is appropriate
to t or maintain control of the scooter.
This manual contains extremely important safety information. It is your responsibility to completely review this information and make sure that
all riders understand all warnings, cautions, instructions and safety topics and assure that all riders are able to safely and responsibly use this
scooter. Pulse Performance Products™ advises that you periodically review and reinforce all information in this manual with all riders, and
that you inspect and maintain your scooter to insure their safety.
The recommended rider age is 13 and older. Any rider that is unable to t comfortably on the scooter should never attempt to ride it. A
parent’s decision to allow their child to use scooter should be based on the child’s maturity, skill and their ability to follow rules.
Do not touch the motor or brakes on the scooter when in use or directly after use as these parts can become extremely hot.
Keep this scooter away from small children and remember that it is intended for use only by persons who are, at a minimum, completely
competent and comfortable while operating this product.
RIDING PRACTICES AND CONDITIONS
Check and obey any local laws or regulations which may affect the locations where the electric scooter may be used.
Always ride defensively. Watch out for obstacles that could catch your wheel or force you to turn suddenly or lose control. Be careful to avoid
pedestrians, other wheeled products (such as skaters, skateboards, scooters, bikes, etc.), children or animals who may enter your path.
Always respect the rights and property of others.
Do not activate the speed control on the hand grip unless you are on the scooter and in a safe, outdoor environment that is suitable for riding.
Do not attempt or perform stunts or tricks on this electric scooter. This product is not made to withstand abuse from jumping, curb grinding or
any other type of misuse or stunts.
Safety and Warnings
Before You Start
Assembly
Computer
Hardware Maintenance
Before You Ride
Repair and Maintenance
Troubleshooting
Scooter Components
Warranty
2-3
4
5-6
7
8
8
9-13
14
15
16
Table of Contents
Safety and Warnings
3Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Maintain a hold with both hands on the handlebars at all times.
Never allow more than one person at a time to ride the scooter.
Never use near steps, water, or swimming pools.
Keep your ngers and other body parts away from the chain, motor, steering system, wheels and all other moving components.
Never ride while using a cell phone or wearing headphones.
Never hitch on to or with another vehicle or pull anyone or anything.
Never immerse the scooter in water; electrical and drive components could be damaged by water or create other possible unsafe conditions.
Ride only on at, dry surfaces such as pavement or level ground without loose debris, such as sand, leaves, rocks or gravel. Water, mud, ice,
bumpy, uneven, slick, or rough surfaces could impair traction and contribute to possible loss of control. Avoid excessive speeds that can occur
from downhill rides which could cause loss of control.
Do not ride at night or in areas of limited visibility.
Do not ride indoors or on surfaces that could become damaged such as carpet or ooring.
Before each cycle of operation, the operator shall perform the preoperational checks specied by the manufacturer; that all guards and pads
originally supplied by the manufacturer are in proper place and in serviceable condition.
That any and all axle guards, chain guards, or other covers or guards supplied by the manufacturer are in place and in serviceable condition.
Persons with the following conditions shall be cautioned not to operate: Those with heart conditions, pregnant women, persons with head,
back, or neck ailments, or prior surgeries to those areas of the body. Persons with any mental or physical conditions that may make them
susceptible to injury or impair their physical dexterity or mental capabilities to recognize, understand, and perform all of the safety instructions
and to be able to assume the hazards inherent in unit use.
Maximum operating speed is 13 MPH (20 KM/H).
Before each ride the following checks will need to be performed to the scooter:
• Ensure that the brake system is functioning properly.
• That all components are properly secured and are functioning according to manufactures specications.
• Components shall be maintained and repaired in accordance with the manufacturers authorized replacement parts with installation
performed by dealers or other skilled individuals.
USING THE BATTERY CHARGER
The battery charger should be regularly examined for damage to the cord, plug, enclosure and other parts. In the event of such damage, if
any is found, the scooter should not be charged until the battery charger has been repaired or replaced.
Use only with the supplied recommended battery charger.
Always use caution when charging.
The battery charger is not a toy and should be operated by an adult.
Never operate battery charger near ammable materials or liquids.
Disconnect the battery charger and unplug from scooter when not in use.
Do not exceed recommended charging time.
Always disconnect the battery charger from the scooter prior to wiping down and cleaning with any liquid.
FAILURE TO HEED TO THE WARNINGS LISTED ABOVE INCREASES RISK OF POTENTIAL SERIOUS INJURY. USE THE
APPROPRIATE CAUTION WHEN RIDING AND ALWAYS WEAR PROTECTIVE GEAR.
Safety and Warnings
4 Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Required Tools
10mm / 8mm wrench
(included)
1 (one) 12mm
wrench
(not included)
1 (one) 14mm
wrench
(not included)
1 (one) 17mm
wrench
(not included)
4mm hex wrench
(not included)
5mm hex wrench
(included)
8mm hex wrench
(not included)
Phillips
screw driver
(not included)
Air/tire pump with
pressure gauge for
schrader type valves
(not included)
battery charger
(included)
brake levercomputer
throttle
disc brake
reset
button
on/off
switch
charging
port
reset button
• Allow up to 25 minutes for assembly, not including initial charge time.
• Allow up to 14 hours for the initial charge (see page 6 for charging information).
WARNING: Remove all packing and items from the display box. Make sure that the power switch is turned
“OFF” before assembling the scooter.
WARNING: DO NOT USE NON-PULSE PRODUCTS WITH YOUR PULSE ELECTRIC SCOOTER. This
scooter has been built to specic Pulse Performance Scooter design specications and should not be modied.
Altering of the original components may or may not be compatible with the design and will void the warranty.
Estimated Assembly Time
Before You Start
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:10
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
5Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
B
局部视图 B
比例 2 : 5
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:5
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
B
局部视图 B
比例 1 : 2
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:5
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
WARNING: It is important to routinely check and maintain tire pressure as this directly impact the safety and
performance of the scooter. Do not overinate tire as this can cause damage to the tire or the wheel.
Assembly
Tools required: 5mm hex wrench, 10mm wrench
Handlebar Steer Tube Assembly
Tools required: Air/tire pump
Tire Ination
Tires are inated to the maximum PSI prior to shipping however some air pressure maybe lost between the manufacture date and your
purchase date.
Using a hand pump with a Schrader-type valve and pressure gauge inate the tires to the recommended PSI as called out on the tire
sidewall. It is not recommended to use pressurized system similar to the ones found at gas stations as these are designed to inate
automobile tires that have much higher air capacity volumes.
1. Depress the push button located on the
rear of the fork and insert the handlebar
steer tube onto the fork. The push button
should align with the locator hole in the
handlebar steer tube and lock the steer tube
securely in place.
2. Tighten the bolts with the 5mm hex
wrench, evenly and securely.
3. Align handlebars (a) both vertically and
horizontally onto handlebar steer tube clamp
(b) and install top clamp (c) and bolts. Install
computer mounting bracket (d) and clamp
nuts and tighten all evenly and securely
with a 5mm hex wrench and 10 mm wrench.
Install computer (e) onto bracket (d) and
install and tighten hardware. Plug cable (f)
into base of computer.
ENSURE TIRES ARE AT THE
CORRECT PSI BEFORE RIDING
THE SCOOTER.
FRONT TIRE PSI: 36 REAR TIRE PSI: 60
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:10
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
A
B
B
局部视图 B
比例 1 : 2
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:10
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
C
A
F
E
D
B
6 Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Assembly
Charging the Battery
WARNING: Batteries must be fully charged before you ride your electric scooter.
Required components: Battery charger
• Initial battery charge time – 14 hours
• Recharges after initial charge – Up to 10 hours
• When scooter is not in regular use batteries need to be charged on a monthly basis to maximize performance.
WARNING: Do not use this product for the rst time until you have charged the battery for at least 14 hours. Failure to follow these
instructions may damage your product and void your warranty.
Note: Do not store the battery in temperatures above 70˚F (21˚C) or below 32˚F (0˚C).
Note: The charger has a small window with one LED light that indicates the charge status. Refer to the illustration on the charger unit for
the actual “charging” and “charged” status indication. Your charger may get warm during use; this is normal and is no cause for concern.
Note: Batteries must be recharged at least once a month even when the scooter is not in use. Failure to do so may result in batteries that
will no longer accept a charge.
WARNING: Any changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
1. Make sure power switch is in the OFF
position before plugging in the charger. Insert
charger into charging port on the right side of
the battery box.
2. Plug the battery charger into a wall power
outlet. The light on the charger housing
should illuminate. Red LED light indicates
battery is charging and a green LED light
indicates battery is fully charged.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
7Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Computer
Using / Resetting The Computer
How To Reset
mph
TRIP
ODO
miles
mph
TRIP
ODO
miles
Ride Time
Odometer/Trip
MPH/Speed
Computer
Reset Button
Ride Time
This setting will show how long you have been riding the scooter. Time activates
only when scooter is turned on and in motion and will reset once the scooter
power button has been turned to the off position.
Trip
This setting will show the distance traveled of your current ride. To reset push the
reset button on the rear of the computer so that it is in the “Trip” mode and hold in
the reset button for approximately 3 seconds and the trip reading will clear.
Odometer
This setting shows the total distance traveled on all rides. By pressing in reset
button for approximately 3 seconds in the odometer mode you can switch
between MPH and KPH.
Reset Button
Quick press of reset button will allow you to switch between “Trip” and “ODO”
modes.
WARNING: Keep your eyes on the road when riding and not on the computer.
8 Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Brake
Check the brakes for proper function. When you squeeze the lever, the brake should provide positive braking action. When you apply the brake with
the speed control on, the brake cut off switch should stop the motor. Make sure that the brakes are not rubbing when lever is not being applied.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken frames are rare, it is possible for aggressive rider to run into a curb or wall and bend or
break a frame. Get in the habit of inspecting your scooter on a regular basis.
Tires
Periodically inspect the wheels for excess wear and always check and maintain tire ination.
Safety Gear
Always wear proper protective gear such as an approved safety helmet. Elbow pads and knee pads are recommended. Always wear athletic shoes
(lace up shoes with rubber soles), never ride barefooted or in sandals, and keep shoelaces tied and out of the way of the wheels, motor and drive
system.
Battery
Make sure the power switch is turned off whenever the scooter is not in use. Never store the product in freezing or below freezing temperatures!
Freezing will permanently damage the battery.
Before you ride always check and for the following:
Safety Gear
Always wear proper protective gear such as:
• Approved safety helmet. (Helmet may be legally required by local law or regulation in your area.)
• Elbow pads and knees pads
• Long sleeved shirt, long pants
• Gloves
• Lace up shoes with rubber soles.
Brake
Check the brakes for proper function. When lever is squeezed it should slow/stop the rear wheel without excessive effort. When you apply
the brake with the throttle on, the brake cut off switch should stop the motor. Make sure that the brakes are not rubbing when the lever is not
being squeezed. Do not ride the scooter if the brakes are not functioning properly.
Throttle
Make sure that before throttle is twisted that you are in an open and safe area to ride, you are balanced on the scooter and have both hands
on the handlebar controls.
Tires
Inspect the wheels for excess wear and replace if necessary. Always check and maintain tire ination.
Frame, Fork and Components
Always carefully inspect your scooter before you ride. Check for cracks, broken worn or loose components which should be repaired or
replaced before you ride.
Battery
Always make sure the power switch is in the “off” position whenever the scooter is not in use. Never store the product in freezing or below
freezing temperatures. These low temperatures will permanently damage the battery.
Hardware Maintenance
WARNING: Always ensure that you are in a safe open area to ride before you engage the throttle. Never twist the throttle without
being on the scooter in a balanced, ready to ride position with both hands on the handlebar controls. Once the power switch is placed in
the “on” position the scooter will move when the throttle is twisted.
Failure to follow these instructions may damage your scooter and void your warranty.
Before You Ride
9Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
局部视图 B
比例 1 : 2
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:10
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
Repair and Maintenance
WARNING: Turn the power switch “OFF” before conducting any maintenance procedures.
Tools required: 10mm wrench
Adjusting the Brakes
WARNING: The brake could be capable of locking up and skidding the wheel if not applied correctly. Always
try and avoid skidding as this could cause you to lose control of the scooter and will cause damage to the tire.
Practice using the brake in an unobstructed open area to become familiar with its function and can make smooth
controlled stops.
B
局部视图 B
比例 1 : 2
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:10
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
1. To adjust the brake cable thread clockwise
(loosen) or counter clockwise (tighten)
the adjuster barrel on the brake lever.
Only turn the barrel in small increments
until the desired adjustment is reached. If
brake continues to need further adjustment
proceed to the next step.
2. If the brake cable is still either too tight or
too loose use a 10mm wrench to loosen the
brake cable pinch bolt for further adjustment
on the cable. Ensure that the 10mm nut is
securely tightened after the adjustment is
made.
3. If the brake cable is adjusted correctly
but there is brake rub (brake contacts rotor
even when brake lever is not engaged) you
can adjust the centering of the brake caliper
on the rotor by turning the brake adjustment
knob clockwise (away from wheel) or counter
clockwise (towards wheel). Rotate front
wheel by hand while adjusting knob until
wheel spins freely.
Loosen
Tighten
brake
adjustment
knob
10 Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Repair and Maintenance
Tools required: 4mm hex wrench, 5mm hex wrench, 14mm wrench, 12mm wrench
Chain and Rear Wheel Replacement
3. Note the location of all rear wheel hardware and ensure to properly reinstall all items.
B
局部视图 B
比例 1 : 2
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:20
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
2. Using a 14mm wrench and a 12mm
wrench, loosen the rear wheel axle nuts. Pull
up on the chain and remove the rear wheel
from the frame.
1. Using a 4mm hex wrench remove the 4
bolts from the rear axle cover on both sides
of the scooter.
11Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Repair and Maintenance
WARNING: If you do not feel comfortable performing the adjustments, consult an authorized Pulse
Performance Products™ customer service representative or a qualied bicycle or motorcycle mechanic.
7. Reinstall side covers with a 4mm hex
wrench. Do not over tighten bolts.
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:20
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
6. Ensure axle hardware is seated correctly
against the frame. After tightening axle nuts
with a 14mm wrench and a 12mm wrench
check wheel alignment and the tracking
of the chain by rotating the wheel counter
clockwise with your hand. Wheel should spin
freely and easily.
局部视图 B
比例 1 : 2
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:25
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
B
局部视图 B
比例 1 : 2
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:20
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
5. Place the chain under tensioner wheel and
onto the rear chain wheel gear and install
replacement wheel into the frame. Do not
tighten axle nuts yet.
4. If replacing the chain, remove the motor
bolts with a 4mm hex wrench. Slide motor
out of the frame slightly so that there is
enough room to remove/replace the chain
onto the motor gear. Replace spacers and
retighten bolts.
Chain and Rear Wheel Replacement (Continued)
12 Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Repair and Maintenance
Tools required: 13mm wrench, 14mm wrench
Front Wheel Replacement
2. Reinstall new replacement wheel
ensuring to note the order and location of all
components.
1. Using an 8mm wrench and a 17mm
wrench loosen and remove the front axle by
turning the wrenches counter clockwise.
3. Reinstall hardware and tighten clockwise
with an 8mm wrench and a 17mm wrench.
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:5
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:5
Super B
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
MATERIAL.
TITLE.
DWG NO.
REV.
SHEET 1 OF 1
SCALE: 1:5
DO NOT SCALE DRAWING
1. DIMENSIONS APPLY BEFORE PLATING OR COATING.
2. REMOVE ALL BURRS, BREAK SHARP EDGES.
3. ALL APPLICABLE BRAVO STANDARDS AND
SPECIFICATIONS APPLY.
UNLESS OTHERWISE SPECIFIED:
METRIC
THIRD ANGLE PROJECTION
1
0.5
0.25
0.1
X.
X.X
X.XX
X.XXX
ANGULAR
C
SIZE
FINISH.
This document is the property of Bravo. All rights are reserved, including copyrights.
TOLERANCES.
DATE
2010-9-1
DRAWN
Sky Shi
APPR
METRIC_C
COLOR.
BRAVO SPORTS
12801 CARMENITA ROAD
SANTA FE SPRINGS, CA, 90670
USA
SHANGHAI OFFICE:
RM 1501/1508, ORIENT CENTER
699 NANJING ROAD WEST
SHANGHAI, CHINA, 200041
13Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Repair and Maintenance
Do not store the battery in temperatures above 70°F (21°C) or below 32°F (0°C).
Disposal: This product contains sealed lead acid batteries which must be disposed or recycled in an environmentally safe manner. Do not
dispose of the batteries in your household trash. Do not dispose of the batteries in a re, this could cause the batteries to leak or explode.
The incineration, disposal in landll and or placing sealed lead acid batteries with household trash is prohibited by law in most areas. Return
exhausted batteries to a state or federal approved lead acid battery recycler or check with your local retailer of vehicle batteries.
Battery Care and Disposal
THIS SCOOTER CONTAINS SEALED LEAD ACID BATTERIES WHICH MUST BE RECYCLED IN AC-
CORDANCE TO YOUR LOCAL AND STATE LAWS. PLEASE CAREFULLY READ AND UNDERSTAND THE
FOLLOWING DISPOSAL INSTRUCTIONS:
WARNING: Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or rechargeable
(nickel-cadmium) batteries.
Do not store the battery in temperatures above 70°F (21°C) or below 32°F (0°C).
WARNING: Make sure to wash your hands after handling batteries as they contain lead compounds.
Only use the supplied battery charger. If battery charger is damaged discontinue use immediately and replace with a Pulse Performance
Scooter recommended battery charger.
Battery Charger
Most of the common replacement parts are available for purchase on line at www.pulsescooters.com.
Replacement Parts
• Check online at www.pulsescooters.com.
• Call (866) 434-6067 to speak with a customer service representative
Repair Help
Wheels and drive system components are subject to normal wear and tear. It is the responsibility of the user to regularly inspect wheels for
excess wear and adjust and replace drive train components as required. Always check and maintain proper tire ination.
Wheels
14 Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
Troubleshooting
Scooter will not run.
Scooter run time is short.
Scooter suddenly stops working.
Scooter runs sluggishly.
Battery is not charged. Fully charge the battery. First charge should be 14 hours and up to
10 hours for recharges.
Wires or connectors are
loose or unplugged.
Battery requires charging.
Reset button has tripped.
Battery will not accept full
charge.
Brakes are not adjusted
correctly.
Brakes are not adjusted
correctly.
Check to ensure that charger is tightly plugged into both the wall
and the scooter.
Fully charge the battery. First charge should be 14 hours and up to
10 hours for recharges.
Check to ensure that battery charger is tightly plugged into both the
wall and the scooter.
The reset button (on the left side of the battery box) will
automatically trip and turn off the power if the motor is overloaded.
An excessive overload (steep incline or too heavy of a rider) could
have caused the motor to overheat and tripped the breaker. If this
occurs (scooter suddenly stops running) wait a few seconds and
then push the reset button in to reset the circuit. Avoid repeatedly
tripping the breaker.
Check all wires and connectors to make sure they are connected
and tight.
Make sure power ow to the wall outlet is on.
Battery may need to be replaced. Even with proper care,
rechargeable batteries do not last forever. The average
rechargeable battery life is 1 to 2 years depending on scooter
conditions and use. Replace only with Pulse Performance
Products™ replacement batteries.
Refer to the instructions on adjusting the brakes on page 9.
Refer to the instructions on adjusting the brakes on page 9.
Problem Possible Cause Solution
Scooter is overloaded.
Unsuitable riding
conditions.
Make sure you do not overload the scooter by exceeding the 150
lbs. (68 kg.) maximum weight limit, going up steep inclines or towing
objects behind the scooter. Avoid overloading the scooter as this will
prematurely wear out the batteries and componentry.
Ride only on solid, at, clean and dry surfaces such as pavement or
level ground.
Scooter makes grinding or loud
noises when motor is running.
Chain is dry. Apply a lubricant to the chain.
15Questions or concerns? Visit our website at www.pulsescooters.com for replacement parts and technical support, or call (866) 434-6067.
12
3
14
27
1
32
7
5
6
2
11
8
22
24
4
23
26
13
17
18
9
28
19
29
15
21
20
16
30
10
25
31
32
31
Scooter Components
part
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
description
Frame
Motor
Front Fork
Headset
Clamp
Right Side Cover
Kickstand
Battery Box
Deck
Rear Wheel
Left Side Cover
Front Wheel
Chain
Disc Brake Caliper
Throttle
Brake Lever
Controller
Battery
Stem Tube
Handlebar
Handlebar Clamp
Charger Port
Reset Button
On/Off Switch
Chain Wheel
Chain Tensioner
Head Tube Cover
Deck Plate
Computer
Computer Bracket
Disc Brake Rotor
Frame Plate
Pulse Performance Products™
A Division of Bravo Sports™
12801 Carmenita Rd.
Santa Fe Springs, CA 90670
© 2014-2015 Pulse Performance Products™ – All Rights Reserved
facebook.com/pulseperfprod
twitter.com/pulseperfprod
Warranty
The manufacturer warranties this product to be free of manufacturing defects for a period of 90 days from the date of purchase. This Limited
Warranty does not cover normal wear and tear, tires, cables, or any damage, failure or loss caused by improper assembly, maintenance,
storage or use of this Pulse Performance Products™ electric scooter.
This Limited Warranty will be void if the product is ever:
• used in a manner other than for recreation or transportation
• modied in any way
• used as a rental
The manufacturer is not liable for incidental or consequential loss or damage due directly or indirectly to the use of this product.
Pulse does not offer an extended warranty. If you have purchased an extended warranty, it must be honored by the store at which the scooter
was purchased from.
For your records, keep your original sales receipt with this manual.
Pulse Performance Products™ Limited Warranty
SB 1918 (CALIFORNIA) DECLARATION
YOUR INSURANCE POLICIES MAY NOT PROVIDE ANY COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER. TO
DETERMINE IF ANY COVERAGE IS PROVIDE CONTACT YOUR INSURANCE COMPANY OR INSURANCE AGENT.

Leave a Comment
